Spiral Point Tap: 1/4-20 UNC, 3 Flutes, Plug, High Speed Steel, Bright Finish
CLE-LINE Spiral Point Tap 1/4-20 UNC, 3-flute plug chamfer HSS bright finish — 1" thread length, 2.5" overall length — ideal for through-hole threading in steel, cast iron and non-ferrous metals.
$13.81 $13.81
Customize
Available Quantity
0 Product Details
Spiral Point Tap: 1/4-20 UNC, 3 Flutes, Plug, High Speed Steel, Bright Finish. 25.4 mm Thread Length (1"), 2-1/2" OAL, Right Hand, H3, Series 0411. Thread Standard: UNC. Chamfer: Plug. Material: HSS (M2). Coating/Finish: Bright/Uncoated. Thread Direction: Right Hand. Coolant Through: No. Number Of Flutes: 3. Material Application: Steel; Cast Iron; Non-Ferrous Metal. Application: Through-Hole Threading. Shank Diameter: 0.2550" (6.48 mm). Square Size: 7.94 mm (0.1910"). Series: 0411. Style: Spiral Point. Threads per Inch: 20. Overall Length (Inch): 2-1/2 (2.5000). Thread Length (Inch): 1 (1.0000). Measurement Type: Fractional Inch. Pack/Kit information from marketplace: Pack of 2 (as listed on marketplace).
- <b>Thread Size</b>: 1/4"-20 <b>Thread Standard</b>: UNC <b>Shank Type - Machining</b>: Straight <b>Thread Limit</b>: H3 <b>Primary Material Application</b>: All Materials <b>Drill Bit Size</b>: #7 <b>65% Thread Drill Size</b>: #5 <b>Country of Origin (subject to change)</b>: United States
- <b>Number of Flutes</b>: 3 <b>Item</b>: Spiral Point Tap <b>Number of Pieces</b>: 1 <b>Tap Size</b>: 1/4" <b>Cutting Direction - Machining</b>: Right Hand <b>Square Size</b>: 0.1910" <b>Extended Neck</b>: Yes <b>Spiral Direction</b>: Neutral <b>Primary Material Application ISO Code</b>: K, N, P <b>75% Thread Drill Size</b>: #7 <b>Threads per Inch</b>: 20 TPI <b>Measurement System</b>: Fractional Inch <b>Series</b>: 0411 <b>Shank Length</b>: 1-1/2" <b>55% Thread Drill Size</b>: #3
- <b>Price For:</b> Pack of 2 <b>Tap Finish</b>: Bright (Uncoated) <b>Thread Direction</b>: Right Hand <b>List Number</b>: E2020 <b>Tap Thread Size</b>: 1/4"-20 <b>Tap Chamfer</b>: Plug <b>Tap Thread Type</b>: UNC <b>Shank Dia.</b>: 0.2550" <b>Overall Length</b>: 2-1/2" <b>Tap Style</b>: Spiral Point <b>Standards</b>: USCTI Table 302 <b>Thread Length</b>: 1" <b>Pitch Diameter Limit</b>: H3 <b>Tap Dimension Type</b>: Inch <b>Tap Material</b>: High Speed Steel
Specifications:
| Materials & Construction | |
| Material | Hss |
| Outer Material | Hss |
| Product Details | |
| Chamfer | Plug |
| Coating/Finish | Bright/Uncoated |
| Coolant Through | No |
| Interrupted Thread | No |
| Material | Hss |
| Material Application | Steel; Cast Iron; Non-Ferrous Metal |
| Material Grade | M2 |
| Number Of Flutes | 3 |
| Oversize | No |
| Product Service Code | 5136 |
| Series | 0411 |
| Style | Spiral Point |
| Thread Direction | Right Hand |
| Thread Limit | H3 |
| Thread Size (Inch) | 1/4-20 |
| Thread Standard | Unc |
| Threads Per Inch | 20 |
| Sizing & Dimensions | |
| Length | 2.5 inches |
| Product Dimensions | Overall Length: 2.5 inches |
| Size | 1/4-20 |
| Weight | 1 pounds |
| Width | 0.2550 inches |
| Technical Specifications | |
| Pitch Diameter Limit | H3 |
| Shank Diameter (Decimal Inch) | 0.2550 |
| Shank Diameter (Mm) | 6.48 mm (0.2550 inches) |
| Shank Length | 1-1/2" |
| Square Size (Mm) | 7.94 |
| Tap Style | Spiral Point |
| Thread Length (Decimal Inch) | 1.0000 |
| Thread Length (Inch) | 1 |
| Thread Length (Mm) | 25.40 mm (1.00 inches) |
| Thread Pitch (Decimal Inch) | 0.05 |
