Ancor 118505 Tinned Copper Battery Cable, 3/0 AWG (81mm2), Red - 50ft
Customize
Red 3/0 AWG Battery Cable - 50' (Part #118505). ANCOR Marine Grade™ wire is manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis. Ultra flexible (Type 3) stranding resists fatigue due to vibration and flexing. ANCOR's proprietary premium vinyl insulation stays flexible even in extreme cold and resists salt water, battery acid, oil, gasoline and ultra-violet radiation. Exclusive insulation is rated at 600V, 105°C dry and 75°C wet, and is resistant to heat and abrasion. Exceeds all UL 1426, US Coast Guard Charter boat (CFR Title 46) and ABYC standards. Manufactured from individual copper strands and tinned to perform in the harshest marine environments. 50 Feet of Red 3/0 AWG marine grade wire. Typical uses include heavy engine cranking, large inverter banks, and primary power distribution on yachts and commercial vessels.
- They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation
- Exceeds all UL 1426, US Coast Guard Charter boat (CFR title 46) and ABYC standards
- Ultra-flexible Type 3 stranding resists fatigue from vibration and provides added corrosion protection
- Manufactured from individual copper strands and tinned to perform in the harshest marine environments
- 50 Feet of Red 3/0 AWG marine grade wire
Specifications:
| Materials & Construction | |
| Color | Red |
| Material | Copper |
| Outer Material | Copper |
| Product Details | |
| Gauge | 3/0 Awg |
| GTIN | 00091887118100 |
| Included Components | Does not apply |
| Number of Cable Strands | Multi Strand |
| Number Of Wires | 1 |
| Strands | Multi Strand |
| Unit Count | 1.0 Count |
| UPC | 091887118100 |
| Sizing & Dimensions | |
| Height | 9.25 inches |
| Length | 10.5 inches |
| Product Dimensions | 10.5 x 10.5 x 9.25 inches |
| Size | 50' |
| Weight | 34.1 pounds |
| Width | 10.5 inches |
| Technical Specifications | |
| Voltage | 600.0 |
