JR Products 13635 5th Wheel/Tongue Jack Switch,Black 1 1 Count (Pack of 1)
Customize
The JR Products 5th Wheel/Tongue Jack Switch (model 13635) is a robust slide switch used on 5th wheel jack motors, tongue jacks and certain slide-out applications. Designed for RV hardware use, it supports Mom-On/Off/Mom-On operations and is IP55 rated for protection. Electrical ratings include 16 Amp @ 125 VAC (CSA), 15 Amp @ 125 VAC (UL), 10 Amp @ 250 VAC, 3/4 H.P. @ 250 VAC and 30 Amp @ 12 VDC. The switch meets RoHS and related specifications and is approved to UL/CSA/CUL standards. Cutout and switch mounting dimensions allow compact installation: cutout 1.300” x 0.75” and switch face 1.736” x 0.95”. Constructed with plastic body and alloy steel contact material, this unit is intended for reliable RV and industrial electrical control applications. Includes: Switch.
- 5th Wheel / Tongue Jack Switch
- Mom-On/Off/Mom-On operations
- UL/CSA/CUL/IP55 RoHS approved
- Cutout: 1.300” x 0.75”
- Switch: 1.736” x 0.95”
- 16 Amp at 125 VAC(CSA), 15 Amp at 125 VAC(UL), 10 Amp at 250 VAC, 3/4 H.P. at 250 VAC, 16 Amp at 12 VDC
- Black pack of 1
- Cutout= 1.736 inch x .95 inch - Switch= 1.30 inch x .75 inch
Specifications:
| Materials & Construction | |
| Color | Black |
| Contact Material | Alloy Steel |
| Material | Plastic |
| Material Type | Plastic |
| Outer Material | Plastic |
| Product Details | |
| Actuator Type | Push Button |
| Circuit Type | 1-way |
| Included Components | Switch |
| Item Dimensions | 5.6 x 1 x 1.6 inches |
| Item Dimensions L x W x H | 5.6 x 1 x 1.6 inches |
| Item Type Name | RV Hardware |
| Model | 13635 |
| Mounting Type | DIN Rail Mount |
| Number of Positions | 3 |
| Operation Mode | ON-OFF |
| Switch Type | Slide |
| Sizing & Dimensions | |
| Height | 1.6 inches |
| Length | 5.6 inches |
| Product Dimensions | 5.6 x 1 x 1.6 inches |
| Product Weight | 0.09 pounds |
| Weight | 1.44 ounces |
| Width | 1 inches |
| Technical Specifications | |
| Connectivity Protocol | X-10 |
| Connector Type | Clamp |
| Contact Type | Normally Closed |
| Control Method | Touch |
| Current Rating | 1 Amps |
| International Protection Rating | IP55 |
| Operating Voltage | 250 Volts |
| Specification Met | Rohs,rohs Approved |
| Wattage | 3750 watts |
