Sea-Dog Bow Eye - Machined 304 Stainless Steel - 7/16" x 3-1/2"
Customize
Bow Eye - Machined 304 Stainless Steel - 7/16" x 3-1/2" These Bow Eyes are for use as a tie-down point on your boat’s bow. The 3/8" shafts have rolled threads. Constructed of corrosion-resistant machined 304 stainless steel. Includes adjustable finish nuts, which provide superior performance over crimp ring-style stern eyes. Can be used in conjunction with Lift Eyes (048330 or 048350) for a more robust lifting assembly. Specifications: Threads: 1/2" NC Sea Dog Part #0800551Stainless Bow Eye 7/16X3 1/2Bow Eye - Stainless Steel Machined AISI 304 stainless steel bow eye comes with finished nuts instead of a crimped ring found on most other bow eyes. Thread is 1/2" NC. Attributes: A = 7/16" B = 3-1/2" C = 1-3/8" D = 4-15/16" E = 1-7/8"Package Quantity = 1
- New
Specifications:
| Materials & Construction | |
| Color | Stainless |
| Material | Stainless Steel |
| Outer Material | Stainless Steel |
| Product Details | |
| Exterior Finish | Stainless Steel |
| Manufacturer Grade | Grade 304 |
| Material | Stainless Steel |
| Metal Type | Stainless Steel |
| Model Number | 0800551 |
| Style | Machined |
| Sizing & Dimensions | |
| Height | 2.25 inches |
| Length | 5.25 inches |
| Product Dimensions | 5.25 x 0.44 x 2.25 inches |
| Size | 7/16" x 3-1/2" |
| Weight | 1 pounds |
| Width | 0.44 inches |
| Technical Specifications | |
| Threads | 1/2" NC |
